A stainless steel body, more durable and hard-wearing than painted plate,
and high quality components.
• Square structural pipe framework, highly resistant, prolonging the product’s
lifetime.
• Easier repairs, with alarms, statistics control, Memory, repair kits and a
drum that can be removed via the front of the appliance, reducing the
minimum space and time required.
• New detergent compartment with non-return system.
• Easy connection for automatic product dispensing.
• Automatic unbalance detection system enabling gentler movement and
prolonging the components’ lifetime.
• G factor of 200 on all models.
• Standard frequency inverter.
NEEDS FIXING TO THE FLOOR
DATI TECNICI |
U.M. |
LR 10 |
LR 13 |
LR 18 |
LR 25 |
Loading capacity |
kG. |
10 |
13 |
18 |
25 |
Volume of the drum |
LT |
100 |
130 |
180 |
250 |
Dimensions of the dum |
Ø mm x P |
532X425 |
620X430 |
620X600 |
700X680 |
Washing speed |
G/min |
50 |
50 |
50 |
47 |
Extract speed |
G/min |
820 |
760 |
760 |
715 |
G" Factor |
200 |
200 |
200 |
200 |
|
Diameter of the door |
Ø mm |
290 |
373 |
373 |
373 |
Hot water power |
KW |
0,75 |
1 |
2,2 |
3 |
total power electrical version |
Kw |
6,75 |
10 |
14,2 |
21 |
total power steam version |
Kw |
0,75 |
1 |
2,2 |
3 |
Power washing motor |
Kw |
0,75 |
1 |
2,2 |
3 |
Dimensions : LxDxH |
mm |
692x805x1155 |
788x870x1300 |
788x1080x1300 |
884x1150x1404 |
Net weight |
Kg. |
208 |
250 |
340 |
500 |
